Radio Shack TRC-447 Service Manual

— 24 —
Assembly, MAIN PCB
Consists of the following:
ELECTRICAL PARTS LIST
MAIN PCB ASSEMBLY
Ref. No. Description RS Part No. Mfr’s Part No.
B1 AT367ZHBA
Capacitors
Notes: All ceramic capacitors are Multilayer (1608) Tape type, unless otherwise specified.
The following codes indicate variations of capacitors against temperature:
B=±10%, CH=0±60 ppm/°C, UJ=−750 ppm/°C±120 ppm/°C, CK=0 ±250 ppm/°C,
F=+30 −80 %,
C1 Ceramic 15 pF 50 V ±5 % CH BCMM811504Z
C2 Ceramic 220 pF 50 V ±5 % CH BCMM812214Z
C3 Ceramic 470 pF 50 V ±5 % CH BCMM814714Z
C4 Electrolytic 4.7 µF 50 V ±20 % C-156 BCAZ814796Z
C5 Ceramic 0.001 µF 50 V ±10 % B BCML811025Z
C6 Ceramic 0.01 µF 50 V ±10 % B BCML811035Z
C7 Ceramic 0.01 µF 50 V ±10 % B BCML811035Z
C8 Ceramic 220 pF 50 V ±5 % CH BCMM812214Z
C9 Ceramic 0.0022 µF 50 V ±10 % B BCML812225Z
C10 Ceramic 0.01 µF 50 V ±10 % B BCML811035Z
C11 Ceramic 0.001 µF 50 V ±10 % B BCML811025Z
C12 Ceramic 0.022 µF 25 V ±10 % B BCML512235Z
C13 Ceramic 33 pF 50 V ±5 % CH BCMM813304Z
C14 Ceramic 0.047 µF 50 V ±10 % B BCML814735Z
C15 Ceramic 0.001 µF 50 V ±10 % B BCML811025Z
C16 Ceramic 0.0047 µF 50 V ±10 % B BCML814725Z
C17 Electrolytic 0.47 µF 50 V ±20 % C-156 BCAZ814786Z
C18 Ceramic 0.47 µF 10 V ±10 % B BCML114745Z
C19 Electrolytic 4.7 µF 50 V ±20 % C-156 BCAZ814796Z
C20 Ceramic 0.01 µF 50 V ±10 % B BCML811035Z
C21 Ceramic 0.0047 µF 50 V ±10 % B BCML814725Z
C22 Electrolytic 4.7 µF 50 V ±20 % C-156 BCAZ814796Z
C23 Ceramic 0.022 µF 25 V ±10 % B BCML512235Z
C24 Ceramic 0.01 µF 50 V ±10 % B BCML811035Z
C25 Ceramic 0.01 µF 50 V ±10 % B BCML811035Z
C26 Ceramic 1 µF 6.3 V ±10 % B BCML901055Z
C27 Ceramic 220 pF 50 V ±5 % CH BCMM812214Z
C28 Ceramic 0.001 µF 50 V ±10 % B BCML811025Z
C29 Ceramic 0.0047 µF 50 V ±10 % B BCML814725Z
C30 Electrolytic 100 µF 10 V ±20 % C-156 BCAZ111016Z
C31 Electrolytic 470 µF 16 V ±20 % C-156 BCAZ314716Z
C32 Ceramic 0.01 µF 50 V ±10 % B BCML811035Z
C33 Electrolytic 1000 µF 25 V ±20 % C-156 BCAZ511026Z
C34 Ceramic 0.1 µF 16 V ±10 % B BCML311045Z
C35 Electrolytic 47 µF 25 V ±20 % C-155 BCAK514706Z
C36 Ceramic 0.001 µF 50 V ±10 % B BCML811025Z
C37 Ceramic 0.001 µF 50 V ±10 % B BCML811025Z
C38 Ceramic 5 pF 50 V ±0.25 pF CH BCMM815091Z
C39 Electrolytic 100 µF 10 V ±20 % C-156 BCAZ111016Z
C40 Ceramic 0.01 µF 50 V ±10 % B BCML811035Z
C41 Ceramic 0.01 µF 50 V ±10 % B BCML811035Z
C42 Ceramic 3 pF 50 V ±0.1 pF CH BCMM813098Z
C43 Ceramic 0.01 µF 50 V ±10 % B BCML811035Z
C44 Ceramic 0.001 µF 50 V ±10 % B BCML811025Z
