— 39 —
Assembly, Volume PCB
Consists of the following:
Volume PCB ASSEMBLY
Ref. No. Description RS Part No. Mfr’s Part No.
B601 AT367ZHBC
Capacitors
Notes: All ceramic capacitors are Multilayer (1608) Tape type, unless otherwise specified.
The following codes indicate variations of capacitors against temperature:
B=±10%
Flat Cable
FC601 WF-353 3.5-70-3.5 8P BWFY3530700
FC602 WF-352 3.5-70-3.5 6P BWFY3520700
Resistors
R601 Carbon Fixed Chip 22 kohm 1/16 W ±5 % BRFC162234Z
R602 Carbon Fixed Chip 0 ohm 1/16 W ±5 % BRFC160004Z
R604 Carbon Fixed Chip 47 kohm 1/16 W ±5 % BRFC164734Z
Variable
VR601 (TP96N00N) RV-888 RY-6313 50KA BRVY0888001
VR602 (TP96N0020F) RV-885 RY-6310 B50K BRVY0885001
VR603 (TP96N00) RV-887 RY-6311 B5K BRVY0887001
VR604 (TP96N00) RV-887 RY-6311 B5K BRVY0887001
VR605 (TP96N00) RV-887 RY-6311 B5K BRVY0887001
To Next Page
