— 40 —
Assembly, LED PCB
Consists of the following:
LED PCB ASSEMBLY
Ref. No. Description RS Part No. Mfr’s Part No.
B701 AT367ZHBD
Capacitors
Notes: All ceramic capacitors are Multilayer (1608) Tape type, unless otherwise specified.
The following codes indicate variations of capacitors against temperature:
B=±10%
C701 Ceramic 0.01 µF 50 V ±10 % B BCML811035Z
C702 Ceramic 0.01 µF 50 V ±10 % B BCML811035Z
Diodes
D701 LED TLR-124 BDAY0100001
D702 LED TLSG-126 BDAY0756001
D703 LED LTD-482GC-08J BDAY1081001
Flat Cable
FC701 WF-353 3.5-70-3.5 8P BWFY3530700
FC702 WF-352 3.5-70-3.5 6P BWFY3520700
Resistors
R701 Carbon Fixed Chip 1.2 kohm 1/16 W ±5 % BRFC161224Z
R702 Carbon Fixed Chip 820 ohm 1/16 W ±5 % BRFC168214Z
R703 Carbon Fixed Chip 680 ohm 1/16 W ±5 % BRFC166814Z
To Next Page
