— 29 —
Ref. No. Description RS Part No. Mfr’s Part No.
D101 HSM88AS TL BDAY0346001
D102~104 Not Used
D105 1N4148 T-77 AX TS 26+ BDAY0246003
D106 1N4148 T-77 AX TS 26+ BDAY0246003
D107~200 Not Used
D201 Switching 1SS356 TW11 BDAY0808001
D202 Switching 1SS356 TW11 BDAY0808001
D203 1N4148 T-77 AX TS 26+ BDAY0246003
D204 1N4148 T-77 AX TS 26+ BDAY0246003
D205 1N4003 BDAY0133001
D206 1N4148 T-77 AX TS 26+ BDAY0246003
D207, 208 Not Used
D209 1N4148 T-77 AX TS 26+ BDAY0246003
D210~300 Not Used
D301 Varicap HVU307 TRU BDAY0940001
D302 Varicap HVU307 TRU BDAY0940001
D303 Zener HZ5B1 TD AX TS 26+ BDAY0492040
D304~405 Not Used
D406 1N4003 BDAY0133001
D407 1N4148 T-77 AX TS 26+ BDAY0246003
D408 Zener HZ5C1 TD AX TS 26+ BDAY0492002
Filter
FT1 Ceramic FL-048 SFELA10M7GM00-B0 BFLY0048001
FT2 Ceramic FL-852 LTS455HTW BFLY0852001
FT3~100 Not Used
FT101 Ceramic FL-048 SFELA10M7GM00-B0 BFLY0048001
FT102 Ceramic FL-743 LTW33-455D BFLY0743001
FT103 Ceramic FL-743 LTW33-455D BFLY0743001
ICs
IC101 Not Used
IC102 S1T3361D01-S0T0 BDEY3282003
IC103 Not Used
IC104 SM8224CM-E2 BDEY3021003
IC301 BU2630F-E2 BDEY2769003
IC401 UC2891 UPD789166GB-685-8ES BDDY1435001
IC402 XC61CC4302PR/XC61AC4302PR BDEY4017003
IC403 RH5RL50AA-T1 BDEY2935003
IC404 Not Used
IC405 AT24CO2N-10SI-1.8 BDEY3517003
Jack
J1, 2 Not Used
J3 Earphone JK-899 JH3501-020D BJKY0899001
J4 Earphone JK-899 JH3501-020D BJKY0899001
To Next Page
