SHIFT
Adjusts the vertical position of the live trace. If held down the trace shifts
– slowly at first and then quickens. Also act as numbers 8 and 13.
AMPLITUDE
Adjusts the vertical amplitude of the trace. If held down the unit will step
through the available gain stages. Also act as numbers 9 and 14.
MEMORY
Enablesa live trace to bestored intoany of 15memory locations.Also acts as
number 10.
Enables any of 15 stored traces to be recalled. Also acts as number 15.
BACKLIGHT
Switches the display backlight ON and OFF. The backlight will switch off
automatically after 5 minutes. Also acts as number 5.
T631 OPERATING MANUAL 13
Radiodetection Ltd. 00901209-6
