8. USE OF THE MEMORY
8.1 STORING A TRACE
Obtain the desired LIVE trace using the method previously described in Section 7.
Press the SAVE key and then select the desired Memory location by pressing the appropriate
key.
The live trace is now stored in the selected memory location, together with the associated
machine settings.
Any trace present in the memory will be overwritten and lost.
8.2 RECALLING A STORED TRACE
Press the RECALL key and then select the desired memory location.
The stored trace will then be displayed on the LCD and memory location confirmed.
The machine parameters are set in accordance with the stored trace, and cannot be altered.
8.3 COMPARING A LIVE AND STORED TRACE
Press the MODE key and select L & M. The displayed memory waveform will be the last one
that was accessed by either SAVE or RECALL.
T631 OPERATING MANUAL 39
Radiodetection Ltd. 00901209-6
