2.1 SAMPLE TRACES
1.
Open circuit/high impedance series faults
Note: Positive (upward) reflection
2.
Short circuit/low impedance shunt faults
Note: Negative (downward) reflection
Radiodetection Ltd. 00901209-6
T631 OPERATING MANUAL 8
Transmit Pulse Reflected Pulse
Transmit Pulse Reflected Pulse
