Display content
Fig. 36. Checkweighing – display content
1 – measurement result
2 – bargraph
3 – working mode name
4 – difference between mass of weighed sample and the center of the tolerance field
(HI/LO)
5 – the values of low (LO) and high (HI) checkweighing thresholds
6 – a pictogram indicating the weighing range of currently weighed sample
(available indications: LO, OK and HI).
Remember to set the 02 Hi Threshold first, as the software automatically checks
whether inserted values are correct and hold within the measuring range of a
balance.
If set values are recognized by the software as incorrect, the balance displays an error
message and returns to parameter settings without saving changes.
Checkweighing with use of database of thresholds (limits)
Checkweighing process can be carried out with use of the DATABASE OF THRESHOLDS,
which is a programmable collection of records comprising:
− 500 records
− Name of a product in each record (max 10 alphanumeric characters)
− The value of HI threshold for each record
− The value of LO threshold for each record
Programming the database of thresholds
