6
Water ONE Zone:
Press the MANUAL WATERING key.
Press
+
or
to select any ONE Zone; then press
NEXT.
MIN
ZONE
Press
+
or
to set the desired Run Time; then
press NEXT to begin watering.
MIN
RUN
TIME
During Manual Watering:
Press
+
or
to adjust watering Run Time
remaining for the active Zone as desired.
Seasonal Adjust
Increase or decrease watering duration (Run
Times) for all Zones.
Press the SEASONAL ADJUST key.
Press
+
or
to increase or decrease the
SEASONAL ADJUST percentage setting.
NOTE: The SEASONAL ADJUST value can be
adjusted from -90% to +100%. For example,
a +50% adjustment means a Run Time of 10
minutes will become 15 minutes.
SETTING
NOTE: SEASONAL ADJUST applies to ALL
programmed irrigation schedules.
