Rain Bird ESP-TM2 User Manual

EN
ESP-TM2 Controller
10
Permanent Days Off
Prevent watering on selected days of the week (for
Odd, Even or Cyclic programming only).
Turn the dial to RUN DAYS.
A
Press Program Select to choose the desired
Program (if necessary).
B
Press and hold Program Select.
C
Press to set the selected (blinking) day as a
Permanent Day Off or press to leave the day
ON.
Special Features
A
Turn the dial to the desired position.
B
Press and hold and at the same time.
SET INTERSTATION DELAY
A station delay (from 1 second
to 9 hours) ensures that a valve
has completely closed before
the next one opens.
RESET TO FACTORY
DEFAULTS
All programmed
schedules will be erased.
SET RAIN SENSOR BYPASS
BY STATION
Tells a station to obey or
ignore a rain sensor.
SAVE PROGRAMMING
RESTORE
PROGRAMMING
SET MASTER VALVE BY
STATION
Allows a station to be
controlled by a master
valve or pump start relay.
SET TO ODD, EVEN OR
CYCLIC WATERING
See Advanced Programming.

Rain Bird ESP-TM2 Specifications

General

Display	LCD
Master Valve/Pump Start Circuit	Yes
Sensor Inputs	1
Delay Between Stations	Yes
Warranty	2 years
Programs	3
Watering Duration	1 minute to 6 hours
Valve Output	24V AC
Weight	2.5 lbs
Zones	6
WiFi Capability	Optional with LNK WiFi Module
Start Times	Up to 4 per program
Watering Days	Customizable
Seasonal Adjust	5% to 200% in 5% increments
Number of Stations	4, 6, 8
Enclosure	Indoor/Outdoor
Stations	4, 6, 8
Battery Backup	No
