Weather Station - Model “PRO”
Nov., 2001 Page 10
Model “PRO”- Weather Station
Cozz GT27145B
have dug on one side of the
hole.
6.0 Insert the other end of the
long sweep elbow into the
center hole in the stainless
steel template. Tape the
end of the elbow with duct
tape.
7.0 Take the three ½” x 12” long
“L” anchor bolts and install
two (2) hex huts on to each
bolt. Insert one in each of
the holes in the template and
install one of the flat washers
and a nut to secure the anchor
bolt to the template.
Refer to FIGURE 5.
8.0 Take the form wire and cut it
into two (2) equal lengths.
Attach one end of one of the
wires to one of the 16p nails
on the form. String the wire
up over the form and to the
long sweep elbow - making a
turn around it. Continue the
wire over to the 16p nail at
the other corner of the form
(located on the same side of
the form as the other nail)
and centering the template
and elbow attach the wire
securely to the nail. Repeat
this same process with the
other piece of form wire -
going to the opposite nails
and further securing the
template, elbow and anchor
bolts in the form.
. 9.0 Steady the template assembly by
putting a 2” spacer between the
template and the top of the form.
Pour the concrete into the hole
and form - it will require
approximately ½ yard - screed
the concrete level with the top
of the form. Check to make
sure the template is correctly
orientated and centered. The
bottom of the anchor bolt
threads should be about ½”
above the top of the concrete.
Check to be sure the template is
“level” in two (2) dimensions.
Use a trowel and edger to finish
the concrete.
BE SURE THAT YOU HAVE
THE TEMPLATE PROPERLY
ORIENTATED IN RESPECT
TO “NORTH”. Refer to
FIGURE 4.
The template should have the
two (2) bolt holes, that are
parallel with one side of the
template, on the north side of
the base.
10.0 Wait 24 hours before removing
the concrete form. Wait 7 days
before mounting the weather
station to the base.
REFER TO NEXT PAGE FOR FIGURES 4 & 5
