Preparation for Use
R&S
®
EB500
8Getting Started 4072.8432.02 ─ 04
1.2.2 Rack Mounting
Ambient temperature
The R&S EB500 should be used in an area where the ambient temperature
does
not exceed –10 °C to +55 °C (EB500 without front control panel) or 0 °C
to 55 °C (EB500 with front control panel), respectively. The R&S EB500 is
fan-cooled and must be installed with sufficient space along the sides to
ensure a free flow of air. Make sure that there is sufficient space for hot air to
escape from the R&S EB500. To ensure sufficient cooling do not attach tele-
scopic rails to the sides of the unit.
1.2.3 In-vehicle Mounting
For use in vehicles, the R&S EB500 can be powered directly from the vehicle's
battery via the DC input.
1.2.4 EMI Protective Measures
In order to avoid electromagnetic interference (EMI), the R&S EB500 may only be
operated when it is closed and all shielding covers are in place. Use only appropriate
shielded signal and control cables with proper termination.
1.2.5
Connecting the R&S EB500 to the Power Supply
Connect the R&S EB500 observing the following sections and instructions for use.
The R&S EB500 is suitable only for DC operation.
1.2.5.1 Connecting to the Power Adapter
The R&S EB500
is connected to the AC supply 100 V to 240 V via an external AC/
DC power adapter and to the socket X1 (10 VDC to 32 VDC) on the rear panel.
Recommended connector: Neutrik® Speakon® NL4FX (see the figure below).
