33
Technical Data
INSTALLER: Please leave these instructions with the User.
DATA BADGE LOCATION : Cooker back, serial number repeater badge below oven door opening.
Country of Destination: GB/IE
Dimensions
Overall height
minimum 900mm maximum 925mm
Overall width
1100mm See ‘Positioning of Cooker’
Overall depth
648mm
Space for fixing
See ‘Positioning of Cooker’
Minimum space above hotplate
650mm
Connections
Electric
220 - 240V 50Hz
Ratings
Total Load At 230V 50Hz 18.3kW (approximate total including oven lights, oven fan etc.)
Hob
Ovens
Multifunction Forced air convection
Energy efficiency class :
on a scale of A (more efficient) to G (less efficient)
B A
Energy consumption based on standard load 0.90 kWh 0.85 kWh
Usable volume (litres)
62 67
Size Medium Large
Time to cook standard load 41 minutes 38 minutes
Baking area
1400 cm
2
1400 cm
2
Grill
2.3 kW
Slow cook oven
1 kW
