Circuit Diagram - Hob
Connection shown in circuit diagram is for single phase. Ratings are for 230V 50Hz
Code Item
A Left hand end dual circuit hob energy regulator
B Left hand rear hob energy regulator
C Left hand front hob energy regulator
D Right hand rear hob energy regulator
E Earth terminal
F Right hand front hob dual energy regualtor
G Right hand warmer hob controller
M Slow cook oven thermostat
W Hob indicator neon
Code Colour
b Blue
bl Black
br Brown
o Orange
r Red
v Violet
w White
y Yellow
