Ranger DST-642D User Manual

37
DRAWING # DESCRIPTION DRAWING # DESCRIPTION
320 Wheel Distance Potentiometer; DST-64T 402 External Support Column
321 Distance arm locking spacer 403 Potentiometer Bracket
322 Nut M8 404 Main Shaft
323 Cross recessed tapping screw ST2.9×9.5 405 Rotary Shaft Spacer
324 Distance Arm Gear; DST-64T 406 Touch Wand Gear; DST-64T
325 Lock Washer 407 Cross recessed pan head screw M4X6
326 Snap Ring 20X1 408 Cross recessed pan head screw M5X10
327 Distance Arm Rod Washer; DST-64T 409 Balancing Weight; DST-64T
328 Distance Arm Spring; DST-64T 410 SHCS M8X16
329 Distance Arm Rod; DST-64T 411 External Bracket Shaft
330 Washer; 6mm Flat 412 Snap Ring 20X1
331 SHCS M6X16 413 External Gauge Spring Hook; DST-64T
332 Distance Arm Head Connect Rod; DST-64T 414 External Gauge Connector
333 Distance Arm Head Spring; DST-64T 415 Touch Wand Rod; DST-64T
334 Distance Arm Head Bushing; DST-64T 416 Hexagon socket set screw with at point M6x6
335 Washer; 12mm at 417 External Gauge Basement; DST-64T
336 Distance Arm Head Weight Holder; DST-64T 418 Touch Wand Pointer Coupling; DST-64T
337 Distance Arm Head Pivot Bushing; DST-64T 419 Touch Wand Pointer; DST-64T
338 Distance Arm Head Screw; DST-64T 420 SHCS M6X30
339 SHCS M6X25 421 Nut M6
340 Nut M10 422 Nut M10
341 Brake Pedal Link Weldment 423 Touch Wand Bearing; DST-64T
342 Brake Metal Thread; DST-64T 424 Touch Wand Return Spring; DST-64T
343 Brake Pedal Return Spring; DST-64T 425 Touch Wand Potentiometer; DST-64T
344 Hood Switch; DST-242D/64T 426 Nut M8
345 Cross recessed pan head screw M3X20 427 Touch Wand Potentiometer Gear; DST-64T
346 Brake Bracket Kit; 64T 428 Hexagon socket set screw with at point M4x5
347 Nut M10 429 Hood Mounting Assembly Upper Plate; DST-64T
348 Washer; 6mm Flat 430 Touch Wand Bracket Cover; DST-64T
349 Presser 431 Touch Wand Bracket Side Cover; DST-64T
350 Rubber Bushing; 64T 432 Cross recessed pan head screw M4X10
351 Motor Bracket; 242D/64T 433 Washer; 10mm split lock
352 Motor; DST-64T 434 SHCS M6X30
353 Washer; 6mm Flat 401-434 Touch Wand Assembly; DST-64T
354 Washer; 6mm Split lock 501 Spacer Ring; DST-242D/64T
355 SHCS M6X25 502 44.5-74.5mm CONE; DST-242D/64T 36mm
356 Nut M8 503 69-94mm CONE; DST-242D/64T 36mm
357 Brake Bracket Spacer; DST-64T 504 90-115mm CONE; DST-242D/64T 36mm
358 Right Brake Stop; DST-64T 505 110-134mm CONE; DST-242D/64T 36mm
359 Brake Shim; DST-64T 506 Quick Nut Cup Cover; DST-242D/64T
360 Brake Spacer Sleeve; DST-64T 507 Quick Nut Cup ; DST-242D/64T
361 HHB M8X60 508 Quick Nut Cover; DST-242D/64T
362 Motor Pully Key; 242D/64T 509 36mm Quick Nut; DST-242D/64T
363 Rubbing Sheet DST-64T 509-1 Quick Nut Release Cover; DST-242D/64T
364 Brake Spring; DST-6T 510 12mm Allen Wrench; DST242D/64T
365 Motor Pulley; DST-64T 511 6mm Allen Wrench; DST-242D/64T
366 Brake Pin 512 4mm Allen Wrench; DST242D/64T
367 SHCS M6X25 513 3mm Allen Wrench; DST-242D/64T
368 Washer; 6mm Split lock 514 Anchor Bolt;3/8 x 3 1/2; DST-242D/64T
369 Washer; 6mm Flat 515 Weight Pliers
370 Left Brake Stop; DST-64T 516 Calibration Weight
371 Brake Bracket; DST-64T 517 36mm Spring; Mounting DST / ZR
372 Brake wheel 518 Wheel Calipers; All DST / ZR650
373 Motor Assembly; (110/220V 0.55KW) 519 Accessory Box; DST-64T
374 Brake Assembly; DST-64T 520 Extension Lever; DST-64T
375 Distance Arm Assembly; DST-64T 521 Distance Arm Head; DST-64T
376 NUT M6 522 SHCS M6X12
377 SHCS M8X25 523 External Gauge Calibration Kit; DST-64T
378 Washer 524 DIAMETER CALIBRATION TOOL;DST-64T
379 Elastic Washer 525 5mm Allen Wrench DST-64T
380 Distance Arm Sticker; DST-64T 526 WEIGHT SHOVEL
401 Hood Mounting Assembly Lower Plate; DST-64T
527 DECAL 3
