Ranger DST-642D User Manual

36
DRAWING # DESCRIPTION DRAWING # DESCRIPTION
101 Display Board DST-64T 210 Vertical Shaft; DST-242D/64T
102 SHCS M6X20 211 Piezo Horizontal Shaft; DST-242D/64T
103 Side Storage Rack; DST242D/64T 212 Weight Indicator Light; DST-64T
104 Washer; 8mm at 213 Chuck Guard; DST-242D/64T
105 SHCS M8X16 214 SSS ST4.8×16
106 Cone Hanger; DST-242D/64T/ZR650Z/RX3040 215 Thread Shaft Plastic Cover; DST-64T
107 Chassis Body; DST-64T 216 Piezo Sensors; DST-242D/64T
108 ON/OFF Switch; DST-64T 217 SHCS M4X12
109 Threaded Shaft/Spindle; DST-64T 218 tooth 64 ; DST-64T
110 Motor; DST-64T 219 SHCS M6X20
111 Power Board Assembly ; DST-64T 220 Bearing Cover
112 Weight Tray; DST-64T 221 Snap ring; 30mm
113 Hood; DST-242D/64T 222 Bearing 6006
114 Hood Mounting Bracket DST-242D/64T 222-1 Bearing 6005
115 SSS M8 x 25; DST-242D/64T 223 Snap ring; 25mm
116 Lower Hood Mount Support; DST-242D/64T 224 Spindle W/Position Board; DST-242D/64T
117 Hood Assembly Set Screw M8x25 225 Encoder Board; DST-64T
118 External Gauge Bracket Weldment 226 Encoder Board Mounting Brkt; DST-242D/64T
119 Bearing 2010; DST-64T 227 Deformation of Beams
120 Snap Ring 20X1 228 Hood Mounting Assembly Bracket; DST-64T
121 Mounting Hood Cover 229 Hood Switch; DST-242D/64T
122 Cross recessed pan head screw M4X12 229-1 Short Hood Switch Wires; DST-242D/64T
123 O-Ring 4.2 x 3.5; DST-64T 229-2 Long Hood Switch Wires; DST-64T
124 Display Assembly Sleeve; DST-64T 230 Hexagon socket set screw with at point M8X12
125 Hexagon socket set screw with at point M6x8 231 Hood Cam; DST-242D/64T
126 Display Assembly Plug; DST-64T 232 Hood Spring; DST-242D/64T
127 Washer; 6mm Flat 233 Adjustable Eye Bolt M8X1.25; DST-242D/64T
128 Washer; 6mm Split lock 234 Washer; 8mm
129 SHCS M6X16 235 Hood Cam Stop; DST-242D/64T
130 Washer; 3mm Flat 236 Nut M8
131 Washer; 3mm Split lock 237 SHCS M8X25
132 Cross recessed pan head screw M3X30 238 Hood Shaft Bushing; DST-242D/64T
133 Membrane Switch; DST-64T 239 Hood Rotating Shaft; DST-242D/64T
134 Display Board Cover; DST-64T 240 Snap ring; 38mm
135 Cross recessed pan head screw M3X40 241 SHCS M12X40
136 Computer/Display Board; DST-64T 242 HHB M8X30
137 Display Board Box; DST-64T 243 Hood Mounting Assembly Cover; DST-242D/64T
138 Washer; 6mm Flat 244 SHCS M8X20
139 SHCS M8X10 245 Washer; 8mm at
140 Elastic Washer 246 Hood Mounting Assembly DST-64T
141 Stator 247 Spindle Assembly
142 Display Board Active Bracket; DST-64T 248 Elastic Washer
143 DECAL 1 301 Cabinet Plate; 64T
144 Power Board; DST-64T 302 Cross recessed pan head screw M4X16
145 Electrical Mounting Plate; DST-64T 303 SHCS M6X16
146 Resistor; DST-242D/64T 304 Brake Pedal; DST-64T
147 Transformer; DST-64T 305 Distance Arm Sleeve; DST-64T
148 SHCS M6X25 306 Distance Arm Sleeve Nut; DST-64T
149 Washer 6mm Split Lock 307 Bearing 2010; DST-64T
150 Washer 308 Cross recessed pan head screw M6X40
151 DECAL 2 309 Internal Pad 3; DST-64T
152 Patch board 310 Distance Arm Basement; DST-64T
153 Inner gauge wire 311 Gear Rail; DST-64T
201 SHCS M8X20 312 SHCS M6X16
202 Washer; 8mm split lock 313 Nut M10
203 Washer; 8mm 314 Washer; 6mm Flat
204 HHB M8X20 315 Washer; 6mm Split lock
205 Washer; 8mm at 316 Cross recessed pan head screw M6X20
206 Motor Belt; DST-64T 317 Hexagon socket set screw with at point M4x4
207 Nut M10 318 Wheel Diameter Potentiometer; DST-64T
208 Piezo Sensor Pad; DST-64T 319 Distance Arm Slide Block; DST-64T
209 Piezo Sensors; DST-64T 155 Power Board Assembly
