26
Err. -1- 1. Balancer Shaft Does Not Rotate. 1. Check the electrical connection.
2. Replace the Power board.
3. Replace the Electrical Motor.
Err. -2- 1. A wheel is not installed on the balancer.
2. A wheel is installed on the balancer but there is no tire.
3. The quick nut is not tight and/or the wheel is not correctly
installed on the balancer.
4. The Electrical Motor belt tension is not correct.
1. Install a wheel on the balancer.
2. Install a tire on the wheel.
3. Remove the tire from the balancer and re-mount
it correctly.
4. Adjust the belt tension for the Electrical Motor.
Err. -3- 1. The wheel/tire combination has too large of an unbalance. 1. Reposition the Tire on the Wheel to reduce the
unbalance.
2. Use a different Tire and/or Wheel.
3. Redo the calibration procedure.
Err. -4- 1. The wheel is rotating counter-clockwise.
2. The wheel is rotating clockwise and the Encoder Board is
malfunctioning.
1. Check the electrical connections for the Electrical
Motor.
2. Adjust and/or Replace the Encoder Board.
Err. -5- 1. The protective Hood is Open. 1. Close the protective Hood.
Err. -6- NA NA
Err. -7- 1. The Computer/Display board memory was cleared. 1. Check that the parameter setting match the sticker
located inside the balancer and redo the factory
calibration.
Err. -8- 1. 100g weight was not attached during the calibration procedure.
2. The piezo sensor(s) wires are disconnected or it is
malfunctioning.
3. Computer/Display board malfunction.
1. Do the calibration procedure and attach the 100g
weight during the correct step.
2. Check the electrical connections for the piezo
sensor(s).
3. Replace the Computer/Display board.
4. Contact Ranger Products.
Failed Calibration Check 1. The wheel used for calibration was too large.
2. The wheel used for calibration had too large of an unbalance.
3. The wheel data was not entered correctly.
4. The SFA (Location) parameter setting is not correct.
1. Use a balanced 14-15 inch wheel and redo the
calibration procedure.
2. Check the wheel information is entered correctly
for the tire you are using for calibration.
3. Contact Ranger Products for instruction to modify
the SFA (Location) parameter.
No Display 1. The balancer is turned off.
2. The balancer has no power going to it.
3. The Computer/Display board is defective
1. Check that the balancer is turned on.
2. Check that the your balancer is connected to a live
electrical source.
3. Replace the Computer/Display board.
No Weight Information Displayed 1. The piezo sensor(s) wires are disconnected or it is
malfunctioning.
2. The Computer/Display board has lost the parameter settings.
1. Check the electrical connections for the piezo
sensor(s).
2. Check that the parameter setting match the sticker
located inside the balancer edit them if necessary.
