GB-4
ZT 220D
Series
ASSEMBLY AND SETUP
3. Set tire pressures to 1.0 kg/cm
2
(14 lbs/in
2
). Tires are overinflated for shipping.
4. INSTALL FRONT CASTER WHEELS
a) Remove caster wheel assemblies bolted to the
pallet.
b) Support the cradle assembly with jackstands or
a hoist.
c) Remove the shipping brackets A from the crate
and cradle.
d) Install the (2) caster wheel assemblies B to the
cradle with (8) M12x30 bolts C and (8) M12
nylock nuts.
e) Remove jackstands or hoist.
To Next Page
