Page #71 background imageLoading...
Page #71 background image
Basic information
This information is really handy when you pick up a Pico and don’t know what is on it!
Basic information includes
program name
program description
program version string
program build date
program url
program end address
program features, this is a list built from individual strings in the binary, that can be displayed (e.g. we will have one
for UART stdio and one for USB stdio) in the SDK
build attributes, this is a similar list of strings, for things pertaining to the binary itself (e.g. Debug Build)
Pins
This is certainly handy when you have an executable called
hello_serial.elf but you forgot what RP2040-based board it
was built for, as different boards may have different pins broken out.
Static (fixed) pin assignments can be recorded in the binary in very compact form:
$ picotool info --pins sprite_demo.elf
File sprite_demo.elf:
Fixed Pin Information
0-4: Red 0-4
6-10: Green 0-4
11-15: Blue 0-4
16: HSync
17: VSync
18: Display Enable
19: Pixel Clock
20: UART1 TX
21: UART1 RX
Including Binary information
Binary information is declared in the program by macros; for the previous example:
$ picotool info --pins sprite_demo.elf
File sprite_demo.elf:
Fixed Pin Information
0-4: Red 0-4
6-10: Green 0-4
11-15: Blue 0-4
16: HSync
17: VSync
18: Display Enable
19: Pixel Clock
Getting started with Raspberry Pi Pico
Binary Information 70
