Battery Backup
Connection
SmartRescue 5 & 10
Page 3
N56W24720 N. Corporate Circle Sussex, WI 53089
800-451-1460 262-246-4828 (fax)
www.rathmicrotech.com www.area-of-refuge.com
• 120V power
• Determine Communication:
 •DedicatedanalogphonelinefromPOTS,PBX,orCentralO󰀩ce
• VoIP - requires use of Rath Model 2100-VoIP to connect SmartRescue to VoIP phone system
 •InternalIntercom(noo󰀨sitecalling)-requiresRathModel2100-Linesim
• Digital or Cellular connect - Call Rath 800-451-1460
• Twisted, shielded 22 or 24 AWG wire cabling to connect each Emergency Phone to the SmartRescue
Base Station
• Use 24V 18/2 wire if remote powering the Emergency Phones
Pre-Installation Requirements
Step 1
Remove the front cover from the SmartRescue
and mount the SmartRescue back box to the wall
usingsuitablemountingscrews(notincluded).
Step 2
Punch out the conduit knockouts for the analog
phone line and phone cabling runs.
Step 3
Connect an analog phone line to the outside
phone line (Diagram A)
Step 4
Connect the backup battery cable to the battery
terminal(batteryincluded).(Diagram A)
Note: If using 2300 Submaster see page 12.
Installation Steps
DIAGRAM A
Outside Phone
Line
