Rational COMBIMASTER

37
6 Electrical connection
Fuse [A]
60 61 62 11 12 21 22
3 AC 200V 16 35 63 63 100 100 200
3 AC 230V 16 32 63 63 100 100 200
3 NAC 400V 10 16 32 32 63 63 100
3 AC 400V 16 32 32 63 63 100
3 NAC 415V 10 16 32 32 63 63 100
3 AC 440V 16 32 32 63 63 100
3 AC 480V 15 32 25 50 50 100
1 NAC 230V 25 50
1 NAC 240V 25 50
2 AC 230V 25 50
2 AC 240V 25 50
Maximum permissible tolerance for input voltage (see type label for input voltage) is
within the range of -15% to + 10%.
