Rational COMBIMASTER

55
10 Wastewater connection
Floor units > Floor units can only use floor drains
Ø 50 mm (2”)
70 mm
(2 3/4“)
max. 1 m (3 ft.)
min. 3°/5%
NOTE!
The average height of the water drainage pipe
is 70 mm.
Options > Additional riser tube to reduce steam escap-
ing from drain pipe with open drain systems.
> Tabletop units:
Increase ground clearance using 110 mm feet
and height-adjustable transport trolley for
mobile oven racks.
> Floor units:
Increase ground clearance by raising up unit
and mobile oven rack.
