INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB
Page 31 of 60
BEFORE REMOVING THE DIAME-
TER-DISTANCE CALIPER, PRESS
THE BRAKE PEDAL AND HOLD IT
DOWN UNTIL THE WEIGHT HAS
NOT BEEN APPLIED, ENSURING IN
THIS WAY THAT, DURING THESE
PHASES, THE WHEEL CAN NOT
ROTATE.
• Weights fitting with laser (at "6 hours").
ON DELIVERY THE MACHINE (IF
PRE-SET WITH FIXED LASER) IS
SET WITH THE CORRESPONDING
OPTION DESELECTED.
TO USE THIS MODE, IT IS NECES-
SARY THAT THE RELEVANT FUNC-
TION IS ENABLED
ON THE
MENU "OPTIONS" DESCRIBED IN
PAR. 15.1.
TO USE THIS WEIGHTS APPLI-
CATION MODE THE OPERATOR
MUST REMEMBER THE PRECISE
POINT AT WHICH THE MEASURE-
MENT WAS TAKEN WITH THE DIS-
TANCE-DIAMETER CALIPER ARM.
At the end of the spin, on the rim at "6 hours" is
displayed a laser beam (blade) indicating the axis
on which to apply the weight. The positioning of the
weight (s) in depth shall be at the discretion of the
operator, depending on where remembers taking
the measure.
BE SURE TO APPLY THE (INTER-
NAL OR EXTERNAL) WEIGHT AS
INDICATED BY THE 2 GREEN
ARROWS (Fig. 46 ref. 2 or 3) ON
THE CORRESPONDING MONITOR
SCREEN.
• Weights fitting at “6 o'clock” (without the use of
lasers).
TO USE THIS MODE, IT IS NECES-
SARY THAT THE RELEVANT FUNC-
TION IS ENABLED ON THE
MENU "OPTIONS" DESCRIBED IN
PAR. 15.1.
TO USE THIS WEIGHTS APPLI-
CATION MODE THE OPERATOR
MUST REMEMBER THE PRECISE
POINT AT WHICH THE MEASURE-
MENT WAS TAKEN WITH THE DIS-
TANCE-DIAMETER CALIPER ARM.
USING THIS MODE, THE MACHINE
ALLOWS YOU TO APPLY ANY AD-
HESIVE WEIGHTS THAT WOULD
BE APPLIED TO "12 HOURS" TO
"6 O'CLOCK". IF, AFTER YOU EN-
ABLE THIS MODE, ON BALANCING
PROGRAM APPEARED AGAIN THE
ICON (ONLY IN THIS CASE)
THE ADHESIVE WEIGHT WILL BE
APPLIED TO "12 HOURS".
At the end of the spin, the wheel stops in place to
apply the weight at "6 o'clock". The positioning of
the weight (s) in depth shall be at the discretion of
the operator, depending on where remembers taking
the measure.
BE SURE TO APPLY THE WEIGHT
(INTERNAL OR EXTERNAL) AS
INDICATED BY THE 2 GREEN
ARROWS (Fig. 46 ref. 2 or 3) ON
THE CORRESPONDING MONITOR
SCREEN.
1297-M007-1_R
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.
