Page #54 background image
GB
Page 54 of 60
INSTRUCTION, USE AND
MAINTENANCE MANUAL
16.0 ERROR SIGNALS
During wheel balancer operation, if wrong commands are given by the operator or device faults occur, an error
code may appear on the monitor screen.
Below is a troubleshooting chart.
Error code Description
2 Planned wheel speed not reached
3 Calibration overcoming
4 Wheel speed stability out of tolerance
5 Encoder calibration error
6 Encoder samples not sufficient
7 Mandrel calibration error
8 Piezo calibration values out of tolerance
9 Wheel rotations not completed
10 Pneumatic mandrel open
11 Incorrect gain calibration
12 Distance-diameter caliper value not released
13 Distance-diameter caliper value not released
14 Firmware error
15 Runout samples not sufficient
17 External data gauge enabled
27 Rotate the wheel to make a complete rotation
28 Piezo calibration error
29 Distance out of tolerance level
31 Distance-diameter caliper released
32 Parameters format incompatible
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.
1297-M007-1_R
