INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB
Page 57 of 60
1819
1461
718
1160
1170
870
1443
1116
926*
1256*
90
997
1191
18.1 Dimensions
Fig. 67
* Only for G3.140RS and GP3.140RS versions
1297-M007-1_R
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.
