4. Safety devices
The stove is fitted with sophisticated safety systems so that, in the case of breakage of one of the individual parts or defects in the flue,
no damage will be caused to the stove and the room in which it is installed. In any case, when a problem arises, the pellets stop falling
immediately and the “ switch off ” phase is activated.
The corresponding alarm will be shown on the display. The details can be seen in chapter 9 ”DESCRIPTION OF ALARMS”.
5. TECHNICAL FEATURES
Unit of
measurement
Francesca
2015
RV 80
Ceramica
Monica
2015
RV 100
Classic
Roma SPILLO RV 100
Height Inch 37.67 39
39.3 44.1 31.5 30.30 42.5
Width Inch 17.32 20.20
20.27 21.7 43.4 28 20.87
Depth Inch 18.46 19.1
18.58 21.9 29.5 25.6 21.25
Weight Lbs 200 270
264 320 550 451 264-242
Diameter of smoke
exit tube
Inch 3.14 3.14 3.14 3.14 3.14 3.14 3.14
Min-max. hourly
consumption of pellets
Lbs/h 1.1 - 3.5 1.1 - 3.5 1.1 - 3.5
1.5 - 5.1 1.6-5 1.8-6.6 1.1-5.0
Supply V - Hz 120 - 60 120 - 60 120 - 60 120 - 60 120-60 120-60 120-60
Hopper capacity Lbs 35 35 35 50 50 44 44
E󰀩ciency * %
77.9 77.9 77.9 80.2 75.5 85 84
Smoke temperature
min - max
°F 176 - 302 176 - 302 176 - 302
200 - 415 240-410 158-195 217-408
The data shown above are indicative and not binding. Ravelli reserves the right to make any
modications for the purpose of improving the performances of the product.
6. Positioning, assembly and installation
6.1 Minimum distance from combustible material
B
R
L
A
Unit of measure-
ment
Francesca
2015
RV 80
Ceramica
Monica
2015
RV 100
Classic
Spillo
RV 100
R =right side
Inch/mm 4 / 101,6 4 / 101,6 4 / 101,6 4 / 101,6
7,87 / 200 11,81 / 300
L = left side
Inch/mm 4 / 101,6 4 / 101,6 4 / 101,6 4 / 101,6
7,87 / 200 11,81 / 300
B = rear side
Inch/mm 2 / 50,8 2 / 50,8 2 / 50,8 4 / 101,6
7,87 / 200 7,87 / 200
A = front side
Inch/mm 39,37 /
1000
39,37 / 1000 39,37 / 1000 39,37 / 1000
39,37 / 1000 39,37 / 1000
D = FRONT oor
protection
Inch/mm 6 / 152,4 6 / 152,4 6 / 152,4 6 / 152,4
6 / 152,4 6 / 152,4
E = SIDE oor
protection
Inch/mm 6 / 152,4 6 / 152,4 6 / 152,4 6 / 152,4 6 / 152,4 6 / 152,4
F = Ceiling
Inch/mm
57 / 1450 57 / 1450 57 / 1450 52 / 1321 -- --
E
D
E
N.B. The floor protection must extrend under the chymney connector and 2 inches (50.8mm) beyond each side
NOTE: Install vent at clearances specied by the
vent manufactures.
*overll heating efficency is determined using higher heating value of the fuel.
