User and maintenance manual for stoves with RDS technology
Pag.18
01/02/2016
Determining Size of Pipe to install
To determine the diameter of pipe to use (3”or 4”), you can use the following guidelines.
Fillout the installation chart (table 1), and calculate your total equivalent pipe length.
Then use the total equivalent pipe length and the altitude in the pipe selection chart. (pic.11) to determine if your installation requires 3” or 4” exhaust pipe.
Table 1: Installation chart
Type of Pipe # of Elbows or
Feet of Pipe
Equivalent
90° Elbows/
Tee (A & G)
x 5 feet (1.5 m)
45° Elbows
(C)
x 3 feet (1.0 m)
Horizontal
(B & F)
x 1 feet (0.3 m)
Vertical
(E)
x 0.5 feet (0.15 m)
Type of Pipe
# of Elbows
or Feet of
Pipe
Equivalent
Total
Equivalent
90° Elbows/
Tee (A & G)
2 x
5 feet
(1.5 m)
10 feet
(3.0 m)
45° Elbows
(C)
1 x
3 feet
(1.0 m)
3 feet
(1.0 m)
Horizontal
(B & F)
3 x
1 feet
(0.3 m)
1 feet
(1,0 m)
Vertical
(E)
8 x
0.5 feet
(0.15m)
1 feet
(1,2 m)
Table 2 - Sample chart for pic.12
Sample installation chart
Pic. 12.See sample installation chart
907,8
443,9 39,1
345
18,2
35,1
19040
352
20
398,8278,7
956,3
187,5
328
35
80
10783
478,9
453,7
Mod.
DESCRIZIONE
Data
Dis.
Appr.
MODIFICHE
54000-00-001
-
MOD.
_
_
A1
(SCHEET)
FORMATO
LISA 2007
85.607
----
COMPLESSIVO STUFA
TOLLERANZE GENERALI PER QUOTE LINEARI, ANGOLARI, SMUSSI E
RACCORDI, CLASSE FINE UNI EN 22768-1, DOVE NON INDICATE
1:5
FCH
P.Belotti
venerdì 14 settembre 2007
SCALA
(SCALE
)
DENOMINAZIONE
(DENOMINATION
)
MATRICE DI PIEGA
will be legally pursued.
diritti a rigore di legge.
and must not be released to other parties without written consent any infringement
in any way utilized for the manifacture of the component of unit herein illustrated
All proprietary right reserved by Society ECOTECK s.r.l. This drawing shall not be reproduced or
ne venire comunicato a terzi o riprodotto. La Societa' proprietaria tutela i propri
disegno non potra' essere comunque utilizzato per la costruzione dell' oggetto rappresentato
Proprieta' della Societa' ECOTECK s.r.l. Senza autorizzazione scitta della stessa, il presente
MODIFICARE SOLO SU CAD
(CHECKED)
CONTR.
(WEIGHT)
PESO Kg
DIS.
MATERIALE
(MATERIAL)
(DESIGNER)
DATA
(DRWG NR.)
N. DISEGNO
(DATE)
CAD DRAWNING HANDLING ON CAD SYSTEM ONLY
MODELLO
(MODEL)
TRATTAM. SUPERFICIALE
Posizione file di disegno:
X:\ECO-PROGETTI\00_STUFE\ARCHIVIO-VALIDI\MODELLI-SW\
Posizione modello 3D:
X:\ECO-PROGETTI\00_STUFE\ARCHIVIO-VALIDI\MODELLI-SW\
Ultimo salvataggio di:
pbelotti -
Data ultimo salvataggio: mercoledì 3 dicembre 2008 10.28.48
Via Kupfer 25035 Palazzolo S/O - BRESCIA - ITALY
A- 90 Degree Elbow
B- 1’ Horizontal Pipe
C- 45 Degree Elbow
D- Standoff Braces
E- 8’ Vertical Pipe
F- 2’ Horizontal Pipe
G- 90 Degree Tee
H- Wall Thimble
Equivalent pipe lenght = (10 + 3 + 1 + 1) ft = 15 ft
If the stove is installed in a place with an altitude of 2000 ft,
it is possible to use either a pipe of 3” or of 4”, as you can
see in the pipe selection chart below.
Pic. 11 .Pipe Selection Chart
Altitude x 1000 Feet
Equivalent Pipe Length (feet)
Altitude x 1000 Feet
Equivalent Pipe Length (feet)
