Raven AIM Command FLEX User Manual

CHAPTER
2
Introduction: 7
CHAPTER 2 INTRODUCTION
The AIM Command FLEX nozzle control system is a pressure based product control system designed for precise
sprayer application in a variety of conditions. Pressure based application control provides accurate control of
droplet size which reduces spray drift during field operations.
AIM Command FLEX is compatible with the ISOBUS communication platform which allows the system to work with
most ISO Virtual Terminals (VTs) and Task Controllers on the market. This manual is intended to provide installation
instructions on the following equipment:
TABLE 1. Patriot Make and Model Information
REQUIRED COMPONENTS
The following components must be installed with the AIM Command FLEX nozzle control system:
• Updated software on field computers or control monitors
• PWM pump control valve
• Case IH compatible flow meter
• Case IH compatible pressure transducer
• 80 (or finer) mesh strainer
NOTE: Air induction style spray tips should not be used with the AIM Command FLEX nozzle control system.
A fan or cone style spray tip is required for the AIM Command FLEX system to operate properly.
TOOLS AND MATERIALS NEEDED
The following tools are recommended for completing the installation:
• SAE and metric sized wrenches and tools
Make Model Model Year
Boom
Configuration
Patriot
2250, 3240, 3340,
4440
2017
120’ Boom
20” Spacing
100’ Boom
20” Spacing
90’ Boom
20” Spacing
80’ Boom
20” Spacing
