Raven CRX Calibration & Operation Manual

CHAPTER
3
P/N 016-4010-001 Rev. A 7
CHAPTER 3 CALIBRATION
INTRODUCTION
FIGURE 1. Home Screen
The RS1 unit contains two sets of software loaded into the Universal Terminal on the field computer.
• Guidance and Steering - Allows the steering and GPS settings within the RS1 unit to be calibrated and
modified.
• Slingshot - Allows the cellular, Ethernet, and WiFi settings within the RS1 unit to be modified.
Raven Guidance
and Steering
Working Set Icon
Slingshot
Working Set Icon
Guidance and Steering Software
Home Screen
Slingshot Software
Home Screen
