DISPLAY SCREEN
PROD 1 PROD 2 DATA FEATURE and DESCRIPTION
SERIAL PORT SCREENS
SPr Prn bEGn CONSOLE DATA PRINTOUT
Sends data through serial port to attached optional
printer to print field begin and field end pages.
SPr FrEF 0 FIELD REFERENCE
Allows user to enter up to a four-digit number to
represent a field. Field reference is included in field
begin and field end pages and the data logger time/
date string.
SPr bAUd 1200 BAUD RATE
Used in GPS mode and data logging mode. Select-
able between 1200 or 9600 baud.
SPr rAtE on RATE CHANGE ALARM ON/OFF
Turns rate change alarm ON or OFF. When rate
change alarm is selected ON; alarm sounds 4 long
beeps when a rate calibration number is changed via
the serial port using a valid change request data
string.
SPr triG 0 DATA LOGGER TRIGGER VALUE
Used in data logging mode. The trigger determines
how often actual rate data string (See Appendix 16 for
data communication string formats) is sent to the
serial port. The trigger may be either feet [meters] or
seconds.
SPr Unit Ft DATA LOGGER TRIGGER UNITS
Used in data logging mode. The trigger unit is select-
able between feet [meters] or seconds.
SPr dLoG oFF DATA LOGGER ON/OFF
Turns data logger ON or OFF.
GLOBAL POSITIONING SYSTEM SCREENS
GPS FiLE 1 GPS FILE REFERENCE
Used only with Raven Grid Application System. See
Grid Application System manual for more details.
GPS SYSt InAC GPS SYSTEM OPTIONS
Used only with Raven Grid Application System. See
Grid Application System manual for more details.
