Raven SCS 700 User Manual

22
DISPLAY SCREEN
PROD 1 PROD 2 DATA FEATURE and DESCRIPTION
DATE SCREENS
dAtE tiME 0:00 TIME
Time of day.
dAtE onth 0 MONTH
Current month of year.
dAtE daY 0 DATE
Current date of month.
dAtE YEAr 0 YEAR
Current year.
dAtE P dn 10 POWER DOWN
Puts Console into low power mode.
FLOW RATE SCREENS
Fr FLo1 0 VOLUME/MINUTE PRODUCT 1
Displays volume per minute of Product 1.
Fr FLo2 0 VOLUME/MINUTE PRODUCT 2
Displays volume per minute of Product 2.
Fr LL 1 0 VOLUME/MINUTE RATE FAULT PRODUCT 1
Turns alarm ON if Product 1 actual volume per minute
falls below this limit.
Fr LL 2 0 VOLUME/MINUTE RATE FAULT PRODUCT 2
Turns alarm ON if Product 2 actual volume per
minute falls below this limit.
ALARM SCREENS
ALr ALrM on AUDIBLE ALARMS ON/OFF
Turns audible alarms ON or OFF for the following:
1) Volume/Area Rate Alarm
2) Volume/Minute Rate Fault
3) Low Tank Fault
4) Vacuum Alarm
5) Flow Alarm
6) Flow Error Alarm
ALr vL 1 on VACUUM AND FLOW FAULT PRODUCT 1
Turns alarms ON or OFF for a vacuum or flow fault in
Product 1 injection pump.
ALr vL 2 on VACUUM AND FLOW FAULT PRODUCT 2
Turns alarms ON or OFF for a vacuum or flow fault in
Product 2 injection pump.
