38 RBR Enterprise Vector 300 LS/Venturi LS RS1/HDU Installation Manual
FIGURE 23. Bulkhead Connector to HDU Cable
3. Connect the end of the RS1 cable to the machine’s mating connector.
FIGURE 24. RS1 Connected to Machine’s Mating Connector
4. Route the 12-pin connector up to the RS1. Secure the cable with zip ties and cable clamps.
