Raven TC1 User Manual

DATE APPR. LTR. DATE APPR.
A 7/27/12 TLB3
B 9/4/12 TLB3
C 9/28/12 TLB3
PART # QTY ITEM #
333-0012-044 2 FTG., ADAPTER, STR., -4 JIC (M) TO -6 SAE O-RING (M) 1
(C) 333-0012-042 2 FTG., ELBOW, 90 DEG. SWIVEL, -6 JIC M/F 2
333-0012-106 2 FTG., ADAPTER, STR., -6 JIC (M) TO -10 SAE O-RING (M) 3
333-0012-108 2 FTG., ELBOW, 90 DEG SWIVEL, -10 JIC M/F 4
(C) 333-0012-110 2 FTG., ADAPTER, STR,M -10 JIC (M) TO -8 SAE O-RING (M) 5
(C) 333-0012-154 1 FTG., ELBOW, 90 DEG. SWIVEL, -4 JIC M/F 6
END 1 SIZE
END 2
214-1000-638 1
10JF 8
10JF90 7
214-1000-780 2
6JF90M
6
6JF 8
214-1000-958 1
4JF90S 4
4JF 9
214-1000-959 1
12JF 8
10JF 10
V
ENDOR:
NOTES
:
1.HOSESTOBEASSEMBLEDANDKITPACKAGEDACCORDINGTO
RAVENSPEC.013‐0159‐016SECTIONSAANDB.
TITLE
CODE IDENT NO. SIZE
M=Metric
14979
A
DRAWN JJP 7/25/12
SCALE
NA
CANBESUPPLIEDBYANYMANUFACTURER/VENDORMEETING
SPECIFICATIONSOUTLINEDONTHISPRINTANDWITH
ENGINEERINGAPPROVAL.
REVISED PER ECO E20094
REVISED PER ECO E20265
OVERALL LENGTH
42
44
46
CUSTOMER APPROVAL REVISIONS
THIS KIT TO CONTAIN THE FOLLOWING ITEMS LISTED BELOW:
DESCRIPTION
LTR. DESCRIPTION DESCRIPTION
RELEASED PER ECO E19910
48
EN F0041 Hyd. Kit Template, REV D SHEET 1 OF 1
I NDUSTRIES, I NC .
SIOUX FALLS, SOUTH DAKOTA
NOTICE:
THIS DRAWING AND THE INFORMATION PROVIDED
ARE PROPERTY OF RAVEN INDUSTRIES INC., AND
MAY ONLY BE USED AS AUTHORIZED BY RAVEN
INDUSTRIES INC.
ALL RIGHTS RESERVED UNDER THE COPYRIGHT
LAWS.
KIT, HYDRAULIC, SMARTRAX,
VECTOR 300 LS/
VENTURI
DRAWING NUMBER
117-0199-126
