RAWLINK 12108 - Introduction and Technical Data; Introduction; Technical Data; Special Safety Directions

50
GB



To get the most out of your new remote-
controlled garage door opener, please read
through these instructions and the attached
safety regulations before use. We also
recommend that you save the instructions
in case you need to refer to them at a later
date.

Voltage: 230 V ~ 50 Hz
Power rating: 100W
Max. door weight: 100 kg
Max. door width: 5 m
Max. door height: 2.5 m
Includes 2 remote controls for outdoor use
and 1 remote control for indoor use.

The door opener must not be exposed to
water or damp.
Do not fi t two door openers to the same
door.

1. Door bracket
2. Lifting arm
3. Wall brackets
4. Rail
5. Rider
6. Ceiling bracket
7. U bracket
8. Motor casing
9. Lamp
10. – button
11. + button
12. Display
13. P button
14. S button
1
7
7
6
5
4
3
2
8
bl
bm
bn
9
8
bo
bp
