20
5.2 Monitoring of the temperature sensor
In the event of damage or malfunction of one of the
temperature sensors, the heating output cuts off (fail safe)
and an errorcode is displayed.
The floor sensor has the following temperature / resistance
values:
15°C / 15,8 kΩ
20°C / 12,5 kΩ
25°C / 10,0 kΩ
30°C / 8,04 kΩ
35°C / 6,51 kΩ
The floor sensor may be replaced by a new one. In the event
of malfunction of the room sensor the entire thermostat
must be replaced.
6. Reset to factory settings.
set value floor sensor mode < >
23°C
set value room sensor mode <
>
20°C
floor sensor offset value <
>
4°C
Reset: switch "off" the thermostat < >. Press < > and < >
simultanously with switching "on" <
> the thermostat "000" is displayed.
Press <
> and “CLR” is displayed. The thermostat is reset.
