3.4 Installation Procedure
a） Place the product in an appropriate position, immobilize it if necessary.
b） Check if the power supply has the correct voltage, and the earth line is connected, make
sure it is firm and reliable;
c
）
Connect the power cable and control cable to the product when power supply is OFF;
d
）
Insert the water pipes into the inlet and outlet;
e
）
Check the output head and clean it if necessary. This procedure must be performed
byRaycus personnel or person authorized by Raycus. Make sure the environment is clean,
or theoutput cable may be contaminated.
f） Prevent the delivery cable from treading, pinching or excessive bending duringinstallation.
g） In the installation of laser output cable and output head process, please make sure that the
surrounding environment is clean, otherwise it may pollute the output head (do not usefans,
which actually may bring more dust).
All the cables can only be connected when power supply is OFF. Charged install
control line may damage the laser.
The laser output optical cable should be kept as natural as possible and not be
distorted.
The too small bending radius of the output fiber cable will damage the laser.
In the process of installation and disassembly, please pay attention to gently hold
the laser output head, do not be subjected to vibration and collision.
Make sure the aperture and the cavity of the processing head is clean.
Prevent it from contamination; Or the aperture will be contaminated when
capped.
