Wuxi Raycus Fiber Laser Technologies Co., Ltd.
User Guide of Raycus 500W～2000W laser
23
4.5 Work Patterns and Control Modes
There are two work patterns for the laser: CW(continuous wave)and pulse pattern. In CW
pattern, the laser emits continuously, and user can set the output power by percentage of output
power.As for pulse pattern, The output beam oflaser is pulsing, transform the waveform by
setting frequency, duty ratio and the percentage of power.
There are threecontrol modes to choose, external control RS-232 mode, external control AD
mode, and Internal controlmode. RS-232 mode is to set up parameters and control laser enable
signal externally. AD mode is to set up parameters (MOD, Analog Quantity) and control laser
enable signal externally. Internal control mode is to set up parameters and control laser enable
signal internally. Each control modes can be achieved in two work patterns: CW mode, pulse
mode.
4.6 Operating Process
Make sure air switch is off, red emergency stop button
（
EMERGENCE STOP
）
is pressed.
All electrical connections must be finishedbefore the laser is powered up;
a
）
Make sure that the PIN 6 and PIN 7 of DB9 SERVICEinterface are connected.
b
）
Turn on the chiller, check that if it is working properly.
c） Turn on the Air switch is on, release red emergency stop button.
d） Open the key switch, start the laser.
4.7 Selection of Control Mode
Raycus provide assorted upper computer software, as shown in Figure 17(Download
theRaycus software and software manual, please log in to Raycus official website).
