Raycus RFL-C1000H User Manual

Wuhan Raycus Fiber Laser Technologies Co., Ltd
User Guide of 1000W CW laser
Raycus User Guide |
Using the Product
29
4.7 Control mode selection
4.7.1 Control mode wiring diagram
Figure 11 Wiring diagram in RS-232 mode
Note: In the above mode, the upper computer of Raycus should be used to
modify the mode: turn off the external red light control, external light out enable
and external AD, and only keep the modulation mode.
Laser
Control card
AC input/
regulator
RS232 or Ethernet Connector
