Wuhan Raycus Fiber Laser Technologies Co., Ltd
User Guide of 1000W CW laser
Raycus User Guide |
Using the Product
6) The serial port or the Ethernet interface sends a shutter opening command
to output the laser, and sends a shutter closing command to turn off the
laser.
Shutdown the laser, please refer to 4.8
4.7.3 External control mode (sequentially connected to 4.6)
Modulation: When the duty cycle of the laser's internal frequency is
set to 100%, the laser works in external modulation mode. The on and off
of the laser is controlled by the "modulation" signal provided by the user
from the external MOD interface. For the timing diagram, see [4.7.5
Control timing Figure];
Gate mode：When the duty cycle of the laser's internal frequency is
set to less than 100%, the laser works in internal modulation mode. The
laser is turned on and off by the user from the external MOD signal and
internal frequency generator. Stop internal pulse generation, see [4.7.5
Control Timing Diagram] for timing diagram;
The laser works in external modulation mode by default after power
on.
5) Turn on the rocker switch, and the panel "power" indicator light is on
6) Wait for 20s, internal main control board circuit initialization is completed
