Raycus RFL-C1000H User Manual

Wuhan Raycus Fiber Laser Technologies Co., Ltd
User Guide of 1000W CW laser
Raycus User Guide |
Using the Product
25
4.4.3 Ethernet TCP / IP interface and connection steps
The default IP address of the laser is 192.168.0.10 and the laser only supports
UDP communication. The laser listens for connections on port 8099. The
command must be sent as a single string in a single packet.
Table 11 Ethernet interface pin definition
PIN
Feature
Description
1
TX+
Transmit Data+
2
TX-
Transmit Data-
3
RX+
Receive Data+
4
N/C
Not Connected
5
N/C
Not Connected
6
RX-
Receive Data -
7
N/C
Not Connected
8
N/C
Not Connected
If conditions permit, please use this interface first to get better communication
stability.
Ethernet connection steps:
First Step: Open Raycus PC software
，
click “Session
→
RS232(or Ethernet)”to
make the host computer communicate with the laser, and then click "Tool
→
Laser IP Set" to enter the laser IP address setting;
Second Step:The default password is "1122334455667788". After passing the
verification, read or set a new laser IP address.
Third Step: If you use the upper computer software of Raycus to control the
laser, you need to find the folder where the upper computer software is located,
