Raycus RFL-C1000H User Manual

Wuhan Raycus Fiber Laser Technologies Co., Ltd
User Guide of 1000W CW laser
Raycus User Guide |
Using the Product
23
input
19
Ready
Digital
output
Laser ready
EVCC
<100mA
20
EGND
Digital
ground
17, 18, 21 pin return
0V
21
EX_RST
Digital
input
Laser fault reset
5-24V
5V
24V
<10mA
22
Laser
Error
Digital
output
Laser fault output
signal
EVCC
<100mA
23
EVCC
Digital
input
External voltage for
output of Ready and
Error signals
5-24V
5V
24V
<100mA
other
NC
Not allowed to
connect
 Please check the level of the control signal to ensure
compliance. Exceeding voltage or voltage fluctuations may
damage the laser.
 Please ensure that the analog signal DOES NOT exceed
10V, or product may be damaged.
 Please use 2 and 3, 8 and 9, 10 and 11 through short circuit.
4.4.2 RS-232 serial port
The following figure shows the RS-232 serial port
Figure 8 RS232 serial port
Each pin is defined as follows.
Table 9 RS-232 serial port definition
