Wuhan Raycus Fiber Laser Technologies Co., Ltd
User Guide of 1500W CW laser
3 Installation
3.1 Dimensions
3.1.1 Overall dimensions of RFL-C1500 cutting laser
The front and rear panel sizes of the small volume 1500W continuous laser
are same as the RFL-C1000 laser, as show in Figure 2.
Figure 2 (a) Front view (Unit: mm)
Figure 2 (b) Rear view (unit: mm)
