Raycus RFL-C2000X User Manual

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL- RFL-C1500X/C2000X
Table 8 Power Connection Requirements
Model
RFL-C1500X
RFL-C2000X
Supply Source
380±10% V AC
50/60Hz
Power Cord
One End of
Power Cord
Four wires labeled L1，L2，L3 and PE.
Sign
Description
L1
，
L2
，
L3
-
> Phase Line
PE
-
> Protective Earth
Note
One end of the power cord is a plug, insert it into the socket 'AC INPUT' on
the rear panel. Notice that the plug is wrong-side preventing. After inserting it,
lock it with the lever.
4.4 Interface Definitions
4.4.1 CTRL-INTERFACE Definitions
The CTRL-INTERFACE is for laser control, the designation and definition is below：
Figure 6 CTRL-INTERFACE
Table 9 Definitions of 24 pin Ctrl Interface
PIN
Name
Type
Level
Drive
Typical
Description
