Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL- RFL-C1500X/C2000X
unconnected, laser enters
RS232 mode
Caution: Please check the control voltage level and ensure that the level is in
accordance with the requirements. Over voltage and voltage ripple may damage
the product.
4.4.2
SERIVCE
Security interface
The Service Security Interface is pin 2 and pin 3 of CTRL-INTERFACE.
The SERVICE connector is a female DB9 interface. If PIN 6-7 are disconnected, the
laser will immediately stop working, and the laser Ready signal will go low.
The laser has pre-shorted the 6 and 7 pins before shipment. If it is not connected, the
InterLock error will be displayed after the laser is powered on.
Caution: Service Security Interface should not connect to any active signal,
or the interface will be damaged, and the laser will report error.
4.4.3 TCP/IP Interface Configuration
The default IP address of this product is 192.168.0.10, only supports UDP communication.
The laser listens for connection on port is 8098, and the command must be sent in a single data
string.
Table 10 The pin definitions of Ethernet interface
