Wuhan Raycus Fiber Laser Technologies Co., Ltd
User Guide of Global Version 2000 W CW laser
Raycus User Guide | Using the Product
4.7.1 The control interface
The control interface is the content displayed on the first page after opening
the clientware, including the user's most commonly used status signal, laser
parameter setting and laser control related functions.
Control abnormal laser reset: Click the reset button to run the abnormal laser
reset command.
Guide laser: the guide laser is turned on or off in the internal control state of
guide laser. After the guide laser is turned on or off, there will be changes in the
guide laser state on the software.
Guide laser external control: turn on the guide laser external control or turn
off the guide laser external control. After turning on and turn off the guide laser
external control, there will be changes of the guide laser external control state in
the software. If the current red external control state, then disable the red control
button.
Control laser parameters: Optical output parameters include power, frequency,
pulse width, and duty cycle. The communication between the software and the
main control board requires only power, frequency, and pulse width.The duty cycle
can be calculated from the pulse width and frequency, and the pulse width can also
be calculated from the duty cycle and frequency. During the software operation,
the frequency and duty cycle will be changed synchronously with the pulse width,
and the duty cycle will also be changed synchronously with the frequency and duty
cycle. The output power can be an integer in the range of [0,100]. The frequency
can be set to a decimal in the range of [0, 5000]. The duty cycle can be set to a
decimal in the range of [0,100].
Control light emission mode: light emission related modes include AD mode,
external enable, external modulation mode, and internal modulation mode. You
can individually control the opening and closing of each mode, and display the
current status of each mode. After the AD mode is turned on, the optical power is
controlled by an external signal, and the power setting function of the software
To Next Page
