Raymarine Autohelm 2000 User Manual

INSTALLATION
DRIVE UNIT
The drive unil is mounled belween the
toiler and a single allachmenl poinl on the
yacht’s structure. After connection to the
yacht’s 12 volt electrical system the unit
becomes operational.
For correcl installation two basic
dimensions are critical (Fig.l):-
Dimension A = 620mm (24.5”)
mounling socket lo tiller pin
Dimenslon B = 460mm (16”)
rudder stock cenlre line to tiller pin
Clamp Ihe tiller on the yacht’s cenlre
line and mark elf dimensions A and B (A
is measured on the STARBOARD side of
the cockpit) using masking tape to locate
the fixing points. Ensure the
measurements are at right angles as
shown.
The drive unit must be mounted
horizontally.
SLOPING RUDDERSTOCK
In certain circumslances it may be more
(/
convenient to mount the unit on lhe
porthand side. When this is the case, the
changeover switch will require
adjustment as lollows. Use a screwdriver
to rotate lhe switch anli.clockwise until
the endstop is reached (Fig. 2).
I
Never force the changeover switch,
light pressure only Is required.
PORTHAND MOUNTING
2
