4.8Alarms

TheAlarmmanagercanbeaccessedfromtheHomescreen.

Example:Activealarmslist

Alarmsareraisedbysystemfunctions,andalsoe xternalequipmentconnectedtoyourdisplay.

WhenanAlarmistriggeredallnetworkedMFDswilldisplayaudibleandvisualwarnings.The

onscreenwarningprovidesdetailsofwhythealarmhasbeentriggered.

Example:Waypointarrivalalarm

TheAlarmmanagercanbeusedto:

•listcurrent,activealarms

•enableanddisablealarms

•adjustalarmthresholds

TheActivealarmslistcanbeaccessedfromthe

Activealarmstab:( Homescreen>Alarms>Active)

AlarmsettingscanbeaccessedfromtheSettingstab:( Homescreen>Alarms>Settings)
