4-6
RayChart 420/420D Chartplotter
The following table lists the Chart Set up parameters and their options, shows
the factory default setting and provides a space for you to make a note of your
new default setting. Each parameter is described in the following subsections.
ParameterParameter
ParameterParameter
Parameter
OptionsOptions
OptionsOptions
Options
FactoryFactory
FactoryFactory
Factory
NewNew
NewNew
New
DefaultDefault
DefaultDefault
Default
SettingSetting
SettingSetting
Setting
ORIENTATION NORTH UP NORTH UP
COURSE UP
HEAD UP
PLOTTER MODE OFF ON
ON
SHOW WAYPOINTS OFF ON
ON
WAYPOINT SYMBOL FISH,SKULL, ANCHOR X
or X
AUTOZOOM OFF ON
ON
SCREEN AMPLIFIER OFF ON
ON
COG VECTOR OFF OFF
ON
ARRIVAL CIRCLE 0.01nm, 0.05nm, 0.1nm
0.1nm, 0.5nm
ANCHOR ALARM OFF, 0.01nm, 0.05nm, OFF
0.1nm, 0.5nm
XTE ALARM OFF, 0.01nm, 0.05nm, OFF
0.1nm, 0.3nm,0.5nm
CHART TEXT OFF ON
ON
CHART BOUNDARIES OFF ON
ON
DEPTH CONTOURS <5M OFF ON
ON
DEPTH CONTOURS 10M OFF ON
ON
DEPTH CONTOURS >20M OFF ON
ON
POSITION CALIBRATION OFF OFF
ON
SET CAL
