9
.2CP470Technicalspecification
Physicalspecification
Dimensions•Width:299
.4mm(11.79in).
•Height:205.6mm(8.1in).
•Height(includingconnectors):285.6mm
(11.2in).
•Depth:84.4mm(3.3in).
W eight
1.539kg(3.39lbs)
P owerspecification
Nominalsupplyvoltage
12V/24Vdc
Operatingvoltagerange
10 .8Vto31.2Vdc
P owerconsumption
30.6W(Maximum)
Current3ARMS
Fuse/break ers
5A
Environmentalspecification
Operatingtemperature
–20°C(–4°F)to+50°C(122°F)
S toragetemperature
–30°C(22°F)to+70°C(158°F)
R elativehumidity
95%
W aterproofrating
IPX6
CHIRPSonarspecification
Frequency
25kHzto255kHz
P oweroutput
Upto2KW(maximum)
Depth
0 .6m(2ft)to3,000m(10,000ft)(Dependantuponconnected
transducer)
T ransducerTransom-mount,in-hull,thru-hull
Connections
•1xP owerconnection
•1xnetworkconnection(RayNetconnector)10/100Mb/s
•1xTransducerconnection
•1xadditionalgroundingpoint
Conformancespecification
Conformance•EN60945:2002
•EMCDirective2014/30/EU
•A
ustraliaandNewZealand:C-Tick,
ComplianceLevel2
T echnicalspecification
89
