3.
1Toolsrequired
Thefollowingtoolsarerequiredtoinstallyourtransducer:
ItemDescription
1P owerdrill
2
13mm(1/2in)wrenchorsuitableadjustablewrenchforanti-rotationnut
3
44mm(13/4in)wrenchorsuitableadjustablewrenchforhullnut
4
Half-roundfile
5
Drillbitforpilotholes
6
9mm(11/32in)drillbit(foranti-rotationhole)
7Marine-gradesealant
8
32mm(11/4in)holecutter(fortransducerstem)
9
Adhesivetape
T oolsrequiredforfairingblockpreparation
Thetoolsbelowarerequiredtoidentifyhulldeadriseangleandtocutthefairingblock.
18
